Electric Skateboard Hub Motors – Swappable

$109.00$209.00

Rubber tire, 105mm.
Buy full set hub motor kit here: https://boundmotor.com/product/hub-motors/

swappable-hub-motor-drive
  • SWAPPABLE HUB MOTOR DRIVE
motor-x-2
  • MOTOR x 1
  • MOTOR x 2
Clear
SKU: Motors Category: Tags: ,

PROS:

  • Draining Water Groove Design
  • Reduce Vibration and Weight by Suspension Holes
  • Anti-Slippy Groove Design
  • Reduce the contact patch area with the road to add the usage life to over 1000 KM
  • Do not need consequently replace tires to save much time and do not need technology
  • Grooves in the tire surface to add anti-slippy function
  • Extremely Increasing the shock absorption features by material and holes
  • Reducing the kneels impact to tremendously add the riding comfortable feelings.

CONS:

  • Add the fraction with the road, loss some power and lead to less range miles.
  • No replaceable tire to add the wheels’stability
  • Torque is less than belt-driven PU wheel

360° VIEWER

SPEC

Motor TypeHub MotorSwappable Hub Motor
Motor TypeFOC
Sensor or SensorlessSensorSensor
Brush or BrushlessBrushlessBrushless
BrakingRegenerative brakingRegenerative braking
KV Value60 (KV / V)60 (KV / V)
Torque1.4 -2.3 NM1.4 -2.3 NM
EfficiencyMore than 90More than 90
Supported battery3S-12S3S-12S
Rated power500W600W
Maximum current50 A50 A
StatorLamination Japan steelLamination Japan steel
Pole pair1010
Rated Loading 1400 mN.m1400 mN.m
Running direction
CCW&CWCCW&CW
Wheels
Diameter105 mm105 mm
Width62 mm66.5 mm
Contact Patch4 mm
Tire Arc8 degree8 degree
Wheel MaterialSilicone RubberSilicone Rubber
Durometer70 A70 A

WHAT'S IN THE BOX?

  • 105mm Hub Motors * 2
Motor Type

SWAPPABLE HUB MOTOR DRIVE

Pack

MOTOR x 1, MOTOR x 2

Customer Reviews

Based on 5 reviews
80%
(4)
20%
(1)
0%
(0)
0%
(0)
0%
(0)
F
F.
Spare motors

I didn't have a problem with my current set of motors but I like to have a backup pair on hand. Not wanting to run out the warranty I installed my newly purchased motors and kept the originals as backup. They work as they should and the install was a breeze.

A
A.S.
2 set for a 4wd

Perfect 👌 i build a 4wd with those beast 😁 Amazing speed and torque.

s
s.h.
Hub Motors

These hub motors are great. They have plenty of power and provide a smooth ride from the softness of the rubber. Boundmotor's customer service was great too. I had a small problem with one of the hall sensors in one of the motors and they promptly sent a response to my email and shipped a replacement hub motor to me.

M
M.
2 x Hub Motors

quality is good, but I needed to pay extra for delivery service (I thought its free shipping?)

Free shipping for orders over $100.

B
B.
Awesome wheels

Great torque an great speed all around really good wheels.
