Hub Motor Kit

Regular price $299.00
Sale price $299.00 Regular price
  • Estimated Delivery:Jun 02 - Jun 06

  • Free Shipping On all orders over $300

Product description

Rubber tires with hollow pour design to reduce vibrations, making your ride smoother and letting you go on rougher terrains. We recommend you set the motors with our VESC-based controller and 12S battery to enjoy the excellent torque and top speed (31mph) these hub motors can offer. Just attach them to your deck like you would any other truck and you are ready to go. Super Simple.

  • Draining Water Groove Design
  • Reduce Vibration and Weight by Suspension Holes
  • Anti-Slippy Groove Design
  • Reduce the contact patch area with the road to increase usage life to over 1000 KM.
  • Do not need consequently replace tires to save much time and do not need technology.
  • Grooves in the tire surface to add an anti-slippy function
  • Extremely Increasing the shock absorption features by material and holes
  • Reducing the kneels impact tremendously add riding comfortable feelings.

SPEC




Motor Type Swappable Hub Motor
Brush or Brushless Brushless
KV Value 60 (KV / V)
Torque 1.4 -2.3 NM
Efficiency More than 90
Supported battery 3S-12S
Rated power 600w/motor
Maximum current 50 A
Stator Lamination Japan steel
Pole pair 10
Rated Loading 1400 mN.m
Running direction CCW&CW
Diameter 105 mm
Width 66.5 mm
Wheel Material Silicone Rubber
Durometer 70 A

WHAT'S IN THE BOX?

  • Trucks * 2
  • 105mm Airless Wheels * 2
  • 105mm Hub Motors * 2
